6.0" LCD Screen 8/10 zones Archway Metal Detector with fire-proof plate material

Brand Name : MCD

Model Number : MCD-800A/C

Certification : ISO , CE

Place of Origin : China

MOQ : 1 pcs

Price : Negotiable

Payment Terms : T/T , Western Union , L/C

Supply Ability : 1500 pcs/month

Delivery Time : Normally within 5 working days

Packaging Details : Carton or Wooden Case

Alarm way : Audio Alert,and LED Location lamp work at same time

Detection zone : 10 Zones(800C) 8 Zones(800A)

Display ways : 6.0" Large screen LCD

Sensitivity : 0-99 adjustable

Tunnel Size : 200(L)*70(W)*56(H)cm

Dimension : 222(L)*80(W)*67(H)cm

Net Weight : 71.5kg

Package Size : Main Body: 230*72*25cm(2 piece /carton) Host Machine:78*47*28cm(1 piece/carton)

Contact Now

6.0" LCD Screen 8/10 zones Archway Metal Detector with fire-proof plate material

Quick Detail :

10 Zones(800C) , 8 Zones(800A)
tender produts
with 10 years experience in this field
12 months warranty
6.0" LCD Screen
0-99 adjustable senstivity

Product Features:

1. 6.0" Large screen LCD, user-friendly, simple and easy Chinese & English operation interface.

2. Optional 8 / 10 detection regions has high brightness LED indicator to position metals more accurately.

3. More than one doors can work together,max 20 sets doors in a group.Digital control over the computer.

4. High, low, mute alarm mode can be adjusted in different occasions according to requirements.

5. The sensitivity of each detection zone can be adjustable independently between 0-99.

6. The combinations of digital and analog technology reduce the false positives,

and improve the door stability.

7. With remote control, easy operation.

8. With modular design, easy demolition and installation.

Product Parameters:

Detection Zone	10 Zones(800C) 8 Zones(800A)
Sensitivity	0-99 adjustable
Alarm way:	Audio Alert,and LED Location lamp work at same time
Dispaly way	6.0" Large screen LCD
Pass rate	>40 people/min
Power	220V AC,50/60HZ
Power wastage	35W
Tunnei size	200(L)70(W)56(H)cm
Dimension	222(L)80(W)67(H)cm
Net weight	61/kg
Gross weight	71.5/kg

Application:

It is popular adopted in Jail house, Customs, Airport, Gymnasiums, Exhibition Centers, factory and so on.

6.0" LCD Screen 8/10 zones Archway Metal Detector with fire-proof plate material

MCD-800 walkthrough metal decetor.pdf
